Every post-frame roof shape

Six roof shapes from the NFBA glossary, each with its own framing configuration, material package and engineering limits — and each modelled, not faked.

What it is

A catalogue of roof SHAPES (gable, gambrel, hipped, mansard, monitor, monoslope), distinct from the roofing SYSTEM (the panel product on the shape). Each entry carries a display name, trade aliases, the NFBA definition, the framing configuration that builds it, the material package the takeoff must count, and a flag for whether its geometry has shipped.

Also called: roof types · roof styles · NFBA roof shapes · gable gambrel hip mansard monitor monoslope
